How to replace the wearing parts of cone crusher?

Cone crushers are commonly used in mining equipment for crushing materials with higher hardness. It is inevitable that the parts need to be replaced. The crushing wall, gears, bearings and sealing devices are the vulnerable parts of the cone crusher. Their replacement methods are different. Different, the following Shanghai Zhuoya Mining Machine will introduce how to replace the wearing parts of the cone crusher?

For the replacement of the cone crushing wall, the cone crusher is the part fixed on the cone with the cone head. Zinc alloy is used between the two. After the newly replaced cone crushing wall has been working for 6-8 hours, check its fastening. If it is found loose, tighten it immediately.

Gear meshing, friction wears the circular plate and causes the gear gap to change. Adding a gasket on the bottom cover can make the gear mesh normally. The thickness of the gasket should be equal to the wear of the circular plate.

Bearing and sealing device, when installing the bowl-shaped bearing, be careful not to damage the oil retaining ring with the wire rope. When assembling, the supporting spherical surface is scraped to ensure that the crushing cone and the bowl-shaped mutual spherical surface are in contact with the inner ring on the outer circle and an annular gap of 0.35-0.5mm should be ensured.
